AIRSTAGE VRF Systems Optional Parts

For Duct type

IR Receiver Unit

UTB-YWC

Flange

UTD-RF204 (Round)

Flange

UTD-SF045T (Square)

Remote Sensor Unit

UTY-XSZX

Long-Life Filter

UTD-LF25NA

For Medium Static Pressure Duct type

Long-Life Filter

UTD-LF60KA

For High Static Pressure Duct type

Auto Louver Grille Kit

UTD-GXTA-W

UTD-GXSA-W

Available for Slim Ducted Indoor Units

Auto Louver Grille Kit

UTD-GXTC-W

UTD-GXSB-W

Available for Slim Ducted Indoor Units

Drain Pump Unit

UTZ-PX1NBA

UTZ-PU1NBA

For Medium Static Pressure Duct type

For MP AHU type

Electric Heater Kit

Optional Heater Kit for Multi-Position Air Handling Units (ARUX Models) for AIRSTAGE J- and V-Series Lineup. The new heater kit offers additional/supplemental heating capacity ranging from 2 kW to 20 kW to suit most light commercial and residential applications.

Feature Highlights

Factory designed & approved Heater Kit
Factory designed & approved Heater Kit
Fits within the air handling unit
Up to 2 stages of heating, total of 20 kW
Improved aux heater control logic

Compatibility

This Electric Heater Kit is only compatible with respective multi-position air handling unit as shown in the table.

Model Name-MP AHU	Model Name-Electric heater kit
ARUX12TLAV2	UTZ-EU02MSA
ARUX12TLAV2	UTZ-EU04MSA2
ARUX18TLAV2	UTZ-EU03MSA
ARUX18TLAV2	UTZ-EU06MSA2
ARUX24TLAV2	UTZ-EU02MSA
	UTZ-EU04MSA
	UTZ-EU08MSA2
ARUX30TLAV2	UTZ-EU03MMA
	UTZ-EU05MMA
	UTZ-EU10MMA2
ARUX36TLAV2	UTZ-EU03MMA
	UTZ-EU06MMA
	UTZ-EU12MMA2
ARUX48TLAV2	UTZ-EU05MLA
	UTZ-EU08MLA
	UTZ-EU16MLA2
ARUX60TLAV2	UTZ-EU05MLA
	UTZ-EU10MLA
	UTZ-EU20MLA2

For Cassette type

Wide Panel

UTG-AKXA-W

UTG-AGYA-W

For Cassette type

Panel Spacer

UTG-BGYA-W

Air Outlet Shutter Plate

UTR-YDZB

For Compact Cassette type Shuts the air outlet when only using as 3 blow out.

Air Outlet Shutter Plate

UTR-YDZK

UTR-YDZC

Shuts the air outlet when only using as 3 blow out.

Insulation Kit For High Humidity

UTZ-KXRA

UTZ-KXGA

For Cassette type

Insulation Kit For High Humidity

UTZ-KXGC

UTZ-KXGB

For Slim Cassette type

Insulation Kit For High Humidity

UTZ-KXGC

For Compact Cassette type

Wireless Remote Controller

UTY-LRHYB1

Fresh Air Intake Kit

For Compact Cassette type

UTZ-VXAA

For Compact Cassette type

Fresh Air Intake Kit

For Cassette type

UTZ-VXRA

UTZ-VXGA

For Cassette type

For Ceiling type

Drain Pump Unit

UTR-DPB24T

UTZ-PU1EBA

For Outdoor Unit

Wind Baffles

Wind Baffles ensure continued operation during high wind conditions, especially with roof-mounted units. Wind Baffles prevent nuisance stoppage of outdoor unit if wind gusts reverse fan rotation while the fan motor is off. They feature solid & sturdy design for durability and reduced vibrations, are the same color as the outdoor unit for better aesthetics and are easy to install.

NOTE:: Wind baffles do not extend low ambient cooling capacities.

More Info

Snow Hoods

Prevent snow from accumulating inside the outdoor unit and causing performance issues. Get complete protection from all sides - all-in-one kit includes Front or Top, Side and Rear parts. Hoods are color matched, factory approved, and are shipped flat pack for easy field assembly.

More Info

Hail Guards (H-Series)

Hail guards ensure that the outdoor unit coil is protected from damaging hail. Engineered to prevent hail damage to coil at any angle. Paint matches outdoor unit. Factory designed.

More Info
